Ors-app exited with code 137

Hello o/
First thanks for all your stuff. It’s amazing.

My goal is to calculate route between 2 or more points.
Optimize how to chain some routes.
End render an these things with leaflet.

I have deployed my own server (mac studio m1 32go) with docker :

And everythings works well.

Then, for adding france-latest.osm.pbf (4.6go) :

  • i stop the server
  • i put france-latest.osm.pbf in the file directory
  • i delete the graph folder
  • i edit the ors-config with that source_file: /home/ors/files/france-latest.osm.pbf
  • i re-start the server and i have this issue : ors-app exited with code 137

I tried many things during hours.
I tried to set this in the docker-compose.yml
XMS: 10g
XMX: 20g
Without succes…

docker-compose.yml

# Docker Compose file for the openrouteservice (ORS) application
# Documentation and examples can be found on https://giscience.github.io/openrouteservice/run-instance/running-with-docker
version: '3.8'

services:
  # ----------------- ORS application configuration ------------------- #
  ors-app:
    # Activate the following lines to build the container from the repository
    # You have to add --build to the docker compose command to do so
    build:
      context: ./
    container_name: ors-app
    ports:
      - "8080:8082"  # Expose the ORS API on port 8080
      - "9001:9001"  # Expose additional port for monitoring (optional)
    image: openrouteservice/openrouteservice:v8.0.0
    # Advanced option! If you different ids to 0:0 and 1000:1000, you have to rebuild the container with the build args UID,GID.
    # The user command is useful if you want easier bind mount access or better security.
    #user: "1000:1000" # Run "mkdir -p ors-docker/config ors-docker/elevation_cache ors-docker/files ors-docker/graphs ors-docker/logs && sudo chown -R 1000:1000 ors" before starting the container!
    volumes:  # Mount relative directories. ONLY for local container runtime. To switch to docker managed volumes see 'Docker Volumes configuration' section below.
      - ./ors-docker:/home/ors  # Mount the ORS application directory (for logs, graphs, elevation_cache, etc.) into its own directory
      #- ./graphs:/home/ors/graphs  # Mount graphs directory individually
      #- ./elevation_cache:/home/ors/elevation_cache  # Mount elevation cache directory individually
      #- ./config:/home/ors/config  # Mount configuration directory individually
      #- ./logs:/home/ors/logs  # Mount logs directory individually
      #- ./files:/home/ors/files  # Mount files directory individually
    environment:
      REBUILD_GRAPHS: False  # Set to True to rebuild graphs on container start.
      CONTAINER_LOG_LEVEL: INFO  # Log level for the container. Possible values: DEBUG, INFO, WARNING, ERROR, CRITICAL
      # If you don't want the default ors-config.yml you can specify a custom file name, that should match the file in
      # your 'config' volume mount.
      #ORS_CONFIG_LOCATION: /home/ors/config/my-ors-config.yml  # Location of your ORS configuration file in the docker container

      # ------------------ JAVA OPTS ------------------ #
      # Configure the memory settings for JAVA or pass additional opts
      # Fore more available ENV properties see Prepare CATALINA_OPTS and JAVA_OPTS
      # in https://github.com/GIScience/openrouteservice/blob/main/docker-entrypoint.sh
      XMS: 10g  # start RAM assigned to java
      XMX: 20g  # max RAM assigned to java. Rule of Thumb: <PBF-size> * <profiles> * 2
      # Example: 1.5 GB pbf size, two profiles (car and foot-walking)
      # -> 1.5 * 2 * 2 = 6. Set xmx to be AT LEAST `-Xmx6g`
      ADDITIONAL_JAVA_OPTS: ""  # further options you want to pass to the java command

      # ----------------- Properties configuration ------------------- #
      # Configure your whole container with only property ENVs.
      # These can be set alternatively or additionally to the yml configuration file.
      # Note, that any values set will override the corresponding values from the yml configuration file.
      # See the ors-config.env file for more options.
      # To have a configuration file-less container, uncomment at least the following properties.
      # The values are examples and provide the default configuration.
      #ors.engine.source_file: /home/ors/files/example-heidelberg.osm.gz
      #ors.engine.graphs_root_path: /home/ors/graphs
      #ors.engine.elevation.cache_path: /home/ors/elevation_cache
      #ors.engine.profiles.car.enabled: true

    # ----------------- ENV file configuration ------------------- #
    # Too many variables for your 'environment:' section?
    # Use an env_file with the ENV properties instead and define everything in there:
    # Values will be overwritten if set in the 'environment' section.
    #env_file: ors-config.env

    # ----------------- Healthcheck configuration ------------------- #
    # The healthcheck is disabled by default. Uncomment the following lines to enable it.
    # The healthcheck allows you to monitor the status of the ORS application.
    # Be careful with long graph builds, as the healthcheck will fail and show 'unhealthy' during this time.
    # This is especially useful if you run your ORS container in a production environment.
    #healthcheck:
    #  test: wget --no-verbose --tries=1 --spider http://localhost:8082/ors/v2/health || exit 1
    #  start_period: 1m
    #  interval: 10s
    #  timeout: 2s
    #  retries: 3
    #  disable: false

# ----------------- Docker Volumes configuration ------------------- #
# Define the Docker managed volumes for the ORS application. For more info on Docker Volumes see https://docs.docker.com/compose/compose-file/07-volumes/
# Volumes are used to persist the data and configuration of the ORS application.
# If you want to use volumes, uncomment the following lines and remove the ./ prefix from the volume paths in 'services.ors-app.volumes'.
#volumes:
#    graphs:
#    elevation_cache:
#    config:
#    logs:
#    files:

ors-config.yml

##### openrouteservice settings file #####
# This file contains parameters for openrouteservice.
# For a full list of possible parameters see https://giscience.github.io/openrouteservice/run-instance/configuration/

##### General server settings #####
#server:
#  port: 8082
#  error:
#    whitelabel:
#      enabled: false
#  # Keep the context-path at / else the war file run with tomcat will have the context-path of /ors/v2 as well.
#  servlet:
#    context-path: /ors
#spring:
#  profiles:
#    active: default
#  mvc:
#    servlet:
#      path: /
##### Settings related to springdoc #####
#springdoc:
#  swagger-ui:
#    enabled: true
#    path: /swagger-ui
#    tryItOutEnabled: true
#    filter: false
#    syntaxHighlight:
#      activated: true
#    showExtensions: true
#  api-docs:
#    path: /v2/api-docs
#    version: OPENAPI_3_0
#  packages-to-scan: org.heigit.ors
#  pathsToMatch: /v2/**
##### Logging settings #####
#logging:
#  file:
#    name: ./logs/ors.log
#  pattern:
#    console: "%d{yyyy-MM-dd HH:mm:ss} %highlight{%-7p} %style{%50t}{Cyan} %style{[ %-40.40c{1.} ]}{Bright Cyan}   %m%n"
#    file: "%d{yyyy-MM-dd HH:mm:ss} %p [%-40.40c{1.}] - %m%n"
#  level:
#    root: WARN
#    org.heigit: INFO
##### openrouteservice specific settings #####
ors:
#  cors:
#    allowed_origins: "*"
#    allowed_headers: Content-Type, X-Requested-With, accept, Origin, Access-Control-Request-Method, Access-Control-Request-Headers, Authorization
#    preflight_max_age: 600
#  messages:
#  ##### ORS endpoints settings #####
#  endpoints:
#    routing:
#      enabled: true
#      attribution: openrouteservice.org, OpenStreetMap contributors, tmc - BASt
#      gpx_name: ORSRouting
#      gpx_description: This is a directions instructions file as GPX, generated from openrouteservice
#      gpx_base_url: https://openrouteservice.org/
#      gpx_support_mail: support@openrouteservice.org
#      gpx_author: openrouteservice
#      gpx_content_licence: LGPL 3.0
#      maximum_avoid_polygon_area: 200000000
#      maximum_avoid_polygon_extent: 20000
#      maximum_alternative_routes: 3
#    matrix:
#      enabled: true
#      attribution: openrouteservice.org, OpenStreetMap contributors
#      maximum_routes: 2500
#      maximum_routes_flexible: 25
#      maximum_visited_nodes: 100000
#      maximum_search_radius: 2000
#      u_turn_costs: -1
#    isochrones:
#      enabled: true
#      attribution: openrouteservice.org, OpenStreetMap contributors
#      maximum_locations: 2
#      maximum_intervals: 1
#      allow_compute_area: true
#      maximum_range_distance_default: 50000
#      maximum_range_distance:
#        - profiles: driving-car, driving-hgv
#          value: 100000
#      maximum_range_time_default: 18000
#      maximum_range_time:
#        - profiles: driving-car, driving-hgv
#          value: 3600
#      fastisochrones:
#        maximum_range_distance_default: 50000
#        maximum_range_distance:
#          - profiles: driving-car, driving-hgv
#            value: 500000
#        maximum_range_time_default: 18000
#        maximum_range_time:
#          - profiles: driving-car, driving-hgv
#            value: 10800
#    Snap:
#      enabled: true
#      attribution: openrouteservice.org, OpenStreetMap contributors
#  ##### ORS engine settings #####
  engine:
    source_file: /home/ors/files/france-latest.osm.pbf
#    init_threads: 1
#    preparation_mode: false
#    graphs_root_path: ./graphs
#    graphs_data_access: RAM_STORE
#    elevation:
#      preprocessed: false
#      data_access: MMAP
#      cache_clear: false
#      provider: multi
#      cache_path: ./elevation_cache
#    profile_default:
#      enabled: false
#      elevation: false
#      elevation_smoothing: false
#      encoder_flags_size: 8
#      instructions: true
#      optimize: false
#      traffic: false
#      maximum_distance: 100000
#      maximum_distance_dynamic_weights: 100000
#      maximum_distance_avoid_areas: 100000
#      maximum_waypoints: 50
#      maximum_snapping_radius: 400
#      maximum_distance_alternative_routes: 100000
#      maximum_distance_round_trip_routes: 100000
#      maximum_speed_lower_bound: 80
#      maximum_visited_nodes: 1000000
#      location_index_resolution: 500
#      location_index_search_iterations: 4
#      force_turn_costs: false
#      interpolate_bridges_and_tunnels: true
#      preparation:
#        min_network_size: 200
#        methods:
#          lm:
#            enabled: true
#            threads: 1
#            weightings: recommended,shortest
#            landmarks: 16
#      execution:
#        methods:
#          lm:
#            active_landmarks: 8
    profiles:
      car:
        enabled: true
#        profile: driving-car
#        elevation: true
#        encoder_options:
#          turn_costs: true
#          block_fords: false
#          use_acceleration: true
#        preparation:
#          min_network_size: 200
#          methods:
#            ch:
#              enabled: true
#              threads: 1
#              weightings: fastest
#            lm:
#              enabled: false
#              threads: 1
#              weightings: fastest,shortest
#              landmarks: 16
#            core:
#              enabled: true
#              threads: 1
#              weightings: fastest,shortest
#              landmarks: 64
#              lmsets: highways;allow_all
#        execution:
#          methods:
#            lm:
#              active_landmarks: 6
#            core:
#              active_landmarks: 6
#        ext_storages:
#          WayCategory:
#          HeavyVehicle:
#          WaySurfaceType:
#          RoadAccessRestrictions:
#            use_for_warnings: true
#      hgv:
#        enabled: false
#        profile: driving-hgv
#        encoder_flags_size: 8
#        encoder_options:
#          turn_costs: true
#          block_fords: false
#          use_acceleration: true
#        maximum_distance: 100000
#        elevation: true
#        preparation:
#          min_network_size: 200
#          methods:
#            ch:
#              enabled: true
#              threads: 1
#              weightings: recommended
#            core:
#              enabled: true
#              threads: 1
#              weightings: recommended,shortest
#              landmarks: 64
#              lmsets: highways;allow_all
#        execution:
#          methods:
#            core:
#              active_landmarks: 6
#        ext_storages:
#          WayCategory:
#          HeavyVehicle:
#            restrictions: true
#          WaySurfaceType:
#      bike-regular:
#        enabled: false
#        profile: cycling-regular
#        encoder_options:
#          consider_elevation: true
#          turn_costs: true
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      bike-mountain:
#        enabled: false
#        profile: cycling-mountain
#        encoder_options:
#          consider_elevation: true
#          turn_costs: true
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      bike-road:
#        enabled: false
#        profile: cycling-road
#        encoder_options:
#          consider_elevation: true
#          turn_costs: true
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      bike-electric:
#        enabled: false
#        profile: cycling-electric
#        encoder_options:
#          consider_elevation: true
#          turn_costs: true
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      walking:
#        enabled: false
#        profile: foot-walking
#        encoder_options:
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      hiking:
#        enabled: false
#        profile: foot-hiking
#        encoder_options:
#          block_fords: false
#        elevation: true
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          HillIndex:
#          TrailDifficulty:
#      wheelchair:
#        enabled: false
#        profile: wheelchair
#        encoder_options:
#          block_fords: true
#        elevation: true
#        maximum_snapping_radius: 50
#        ext_storages:
#          WayCategory:
#          WaySurfaceType:
#          Wheelchair:
#            KerbsOnCrossings: true
#          OsmId:
#      public-transport:
#        enabled: false
#        profile: public-transport
#        encoder_options:
#          block_fords: false
#        elevation: true
#        maximum_visited_nodes: 1000000
#        gtfs_file: ./src/test/files/vrn_gtfs_cut.zip

Thanks for all

Everything works well with :
XMS: 2g
XMX: 6g

:smiley:

2 Likes

Hi @azurha,

great that worked out for you. it’s still strange, that the issue would be fixed with lower memory settings.
This could have been an issue with how much resources your docker can use on the machine. If you are using docker desktop you can adjust that in settings->resources.

Then you might also be able to run ors with more memory.

Best regards
